The 19mm Angled & Offset Electrode Pair is the essential solution for complex spot welding tasks where standard straight access is impossible. Designed specifically for high capacity industrial systems like the Tecna 8005D and 6075A-8031, these electrodes feature a robust 19mm (3/4") diameter with a precision BS807 5° taper for maximum electrical conductivity and mechanical stability.
This pair includes one Angled and one Offset electrode, allowing the welding tips to bypass structural ribs, flanges, or interior reinforcements. Whether you are performing high strength automotive collision repair or industrial sheet metal assembly, these electrodes ensure consistent pressure and current delivery even at challenging angles.
Key Features
Tecna Model Specific: Guaranteed direct fit for Tecna 8005D and 6075A-8031 spot welding systems.
19mm (3/4") Industrial Taper: Features the standard BS807 5° Taper for a secure, high current connection to the welding arms.
Angled & Offset Geometry: Specifically designed to clear obstructions and reach "hidden" weld points in complex assemblies.
Premium CuCrZr Alloy: Manufactured from Copper Chrome Zirconium for maximum hardness and thermal conductivity, resisting "mushrooming" under high pressure cycles.
High Strength Pressure Handling: The 19mm body provides the structural rigidity needed for high kVA industrial welding without bending.
Matched Pair: Includes both the upper and lower specialised electrodes required for offset configurations.
