25ft Titanium 20F Tig Torch [10K Pot]

The Titanium 20F TIG Torch represents the pinnacle of water cooled TIG technology. Designed for high amperage production environments, the 250 Amp WP20F style head is significantly smaller than air cooled torches, providing the dexterity needed for intricate welds on heavy duty materials. This "F" model features a Flexible Neck, allowing you to bend and shape the torch head to navigate around complex geometry, internal pipe joints, and restricted chassis sections.

Equipped with a 25ft (7.6m) extended lead set, this torch offers massive mobility for large scale fabrication. To ensure precision, an integrated 10K Potentiometer (Pot) is mounted directly to the handle, giving you surgical control over your amperage without needing a foot pedal or returning to the machine. The entire four line bundle (Power, Gas, Water In, and Water Out) is encased in High Density Industrial Sheathing to protect the leads from the abrasive shop floor, hot spatter, and UV degradation.

Key Features

20F Flexible Neck: Reshape the torch head on the fly to reach difficult angles and reduce wrist strain.

250A @ 100% Duty Cycle: Water cooled design allows for continuous high amperage welding on aluminium and stainless.

10K Potentiometer Handle: Thumb dial control for real time amperage adjustment, essential for managing heat soak.

Extended 25ft Reach: Twice the standard length for welding large trailers, tanks, and structural frames.

Industrial Sheathed Leads: Heavy duty protective sleeve bundles all four lines into a snag free, protected package.

Standard WP20 Consumables: Uses standard 9/20 series collets, gas lenses, and cups for easy maintenance.
