Features and Applications
Micro-alloyed steel, triple de-oxidised (Ti, Al, Zr) suitable for the welding of C-Mn and low-alloy steels.
Ideal for use on greasy and oxidised surfaces subsequent to any coating processes. (i.e. galvanised steel)
Works well at low temperatures.
Typically used on tanks, containers, car industry, structural work, household appliances, pipelines, boilers, naval & petrochemical sectors etc.
Green wire is produced using virgin raw materials sourced from specialised steel mills, which ensures consistent reliability and quality.
Test Certificates can be found online @wilkinsonstar247.com
Typical Base Materials
A106, A210, A234 S355J2, S380N, P235GH, GS 45, P295GH, P355GH, S355N*
* Illustrative, not exhaustive list
|EN ISO 636-A - W 2Ti
|AWS A5.18 - ER 70S-2
|Chemical Composition % (Typical)|
|Mechanical Properties (Typical)
|Tensile Strength||560 MPa|
|Yield Strength||480 MPa
|Impact Strength||50 J|
Mechanical properties are approximate and may vary based on the heat, shielding gas, welding parameters and other factors.
EN ISO 14175 - TIG: I1 (Argon)
EN ISO 6947 - PA, PB, PC, PD, PE, PF
Liability: Whilst all reasonable efforts have been made to ensure the accuracy of the information contained, this information is subject to change without notice and can be only considered as suitable for general guidance.
